/SRMERP/D_WF_003 SAP table for – Table for persistent class /SRMERP/CL_WF_PROCESS_LEVEL

Here we would like to draw your attention to /SRMERP/D_WF_003 table in SAP. As we know it is being mainly used with the SAP MM-PUR (Purchasing in MM) component which is coming under MM module (Material Management). /SRMERP/D_WF_003 is a SAP standard transparent table used for storing Table for persistent class /SRMERP/CL_WF_PROCESS_LEVEL related data in SAP. It comes under the package /SAPSRM/WF_CORE.

SAP /SRMERP/D_WF_003 table

Table /SRMERP/D_WF_003 technical data

Table/SRMERP/D_WF_003
Data storingTable for persistent class /SRMERP/CL_WF_PROCESS_LEVEL
ModuleMM
ComponentMM-PUR
SAP Package/SAPSRM/WF_CORE
Delivery ClassA – Application table (master and transaction data)
Table CategoryTRANSPARENT

SAP /SRMERP/D_WF_003 Table Fields

Here is the details of each fields in this table.You can find the discription, data type and assigned lenth of each of the fields in /SRMERP/D_WF_003 table.

  • CLIENT : Client
    Its a key field. Its data type is C (Character String) with field length 3
  • DS_FILTERED
    Its data type is C (Character String) with field length 1
  • DOC_CHANGEABLE
    Its data type is C (Character String) with field length 1
  • LEVEL_POS
    Its data type is X (Byte string) with field length 4
  • PREV_LEVEL_CL
    Its data type is X (Byte string) with field length 16
  • PREV_LEVEL_ID
    Its data type is X (Byte string) with field length 16
  • NEXT_LEVEL_CL
    Its data type is X (Byte string) with field length 16
  • NEXT_LEVEL_ID
    Its data type is X (Byte string) with field length 16
  • PROCESS_CL
    Its data type is X (Byte string) with field length 16
  • PROCESS_ID : DMD: Object Number
    Its data type is X (Byte string) with field length 16
  • STEP_COUNTER
    Its data type is N (Character String with Digits Only) with field length 3
  • ID : Demo hierarchy: Node ID
    Its a key field. Its data type is X (Byte string) with field length 16
  • LEVEL_STATUS
    Its data type is C (Character String) with field length 10
  • RESOLVER_PARAM
    Its data type is C (Character String) with field length 32
  • LEVEL_GUID
    Its data type is X (Byte string) with field length 16
  • LEVEL_SEQNR
    Its data type is N (Character String with Digits Only) with field length 3
  • LEVEL_TYPE
    Its data type is C (Character String) with field length 1
  • RESOLVER_NAME
    Its data type is C (Character String) with field length 32
  • EVALUATION_ID
    Its data type is C (Character String) with field length 32
  • TEMPLATE_ID : Alert configuration: guid
    Its data type is C (Character String) with field length 14
  • APPROVAL_TASK_ID
    Its data type is C (Character String) with field length 14
  • DECISION_TYPE
    Its data type is C (Character String) with field length 1
